Hailo-8 M.2 AI
Acceleration Module

Hailo-8 Overview

Step Up Your Edge Product Performance with Best-In-Class AI Processor Packaged in A Module

The Hailo-8 M.2 Module is an AI accelerator module for AI applications, compatible with NGFF M.2 form factor M, B+M and A+E keys. The AI module is based on the 26 tera-operations per second (TOPS) Hailo-8 AI processor with high power efficiency. The M.2 AI accelerator features a full PCIe Gen-3.0 2-lane interface (4-lane in M-key module), delivering unprecedented AI performance for edge devices. The M.2 module can be plugged into an existing edge device with M.2 socket to execute in real-time and with low power deep neural network inferencing for a broad range of market segments. Leveraging Hailo’s comprehensive Dataflow Compiler and its support for standard AI frameworks, customers can easily port their Neural Network models to the Hailo-8 and introduce high-performance AI products to the market quickly.

Learn about our partner ecosystem here.

Breathe life into your edge applications with the Hailo AI processors


Key Features and Benefits

Powered by 26 Tera-Operations Per Second (TOPS) Hailo-8 AI Processor

Best-in-class power efficiency

Enabling real-time, low latency, and high-efficiency AI inferencing on edge devices

Highest cost-efficiency (TOPS/$) compared with existing solutions

Scalable, enabling simultaneous processing of multi-streams & multi-models

Robust software suite supports state-of-the-art deep learning models & applications out-of-the-box

Supporting extended temperature range of -40°C to 85°C

Fast time to market using a standard form factor module, with key M, key B+M & key A+E.

Optional extensions for Key M & Key B+M

Technical Specifications

Form Factor M.2 Key M Key B+M Key A+E

AI Processor

Hailo-8 AI processor with up to 26 TOPS and best-in-class power efficiency


22 x 42 mm with breakable extensions to 22 x 60 and 22 x 80 mm

22 x 30 mm


PCIe Gen-3.0, 4 lanes (up to 32 Gbs)

PCIe Gen-3.0, 2 lanes (up to 16 Gbs)

Supported Frameworks

TensorFLow, TensorFlow Lite, ONNX, Keras, Pytorch

Supported OS

Linux, Windows



Explore More

Product Brief
Hailo-8 M.2 AI Acceleration Module Product Brief


  • Hailo-8 figures are based on SDK version 3.12.0 (November 2021), measured at room temperature on a single Hailo-8 device through PCIe interface on a Hailo evaluation board (system host: Intel® Core™ i5-9400 CPU @ 2.90GHz)
  • Intel Myriad X figures sourced from here (retrieved 12/07/21 for version 2021.4)
  • Google Edge TPU figures sourced from here (with power figures); here (throughout only), retrieved 12/07/21 ; and there (retrieved 08/08/21). FPS is converted from latency in ms (1 divided by ms/1000)
  • Hailo-8 and Edge TPU figures are for batch=1 and INT8, while Myriad X is batch=1 and FP16



Order Starter Kit

Get started with

The Hailo-8 starter kit includes:

  • Hailo-8 M.2 Module (key M, key A+E or key B+M)
  • Thermal management kit includes the metal cubes, thermal pads, and thermal adhesive tape
  • Screw and screwdriver

Hailo-8 Starter Kit is available now!

Hailo-8 Starter Kit Module Part Number Price

M.2 Key M 2280 ET



M.2 Key B+M 2280 ET



M.2 Key A+E 2230 ET



Explore More

Product Brief
Hailo-8 M.2 Starter Kit Product Brief
